Panel Mount +/-50Amp AC/DC Current Sensor Module Board, based on ACS758.

MD-D1085/50A-1
CZH-LABS Panel Mount +/-50Amp AC/DC Current Sensor Module Board, based on ACS758.
Sold:131
Have a question?
Price:
USD
$28.00
Wholesale:
10-99
$25.20
100+
$22.40
Quantity:
-
+
(911 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
Please select the information you wantX
Add to Favorite Items
  • Description
  • Reviews

Current Sensor Module Board, +/-50 Amp, Panel Mount Version.

Features：
The item of current sensor module provides economical and precise solutions for AC or DC current sensing. Typical applications include motor control, load detection and management, power supply and DC-to-DC converter control, inverter control, and overcurrent fault detection.
Output voltage proportional to AC or DC currents.
FR-4 fiber glass PCB, dual copper layers.
100% new, never used.

Electrical Parameters:
Load Maximum Current: ±50A.
Load Frequency Bandwidth: DC ~ 120 kHz.
Isolation Voltage: 4800V AC.
Sensitivity: 40mV/A.
Operating Voltage: Regulated 5VDC, or 8 ~ 35VDC.
Operating Current: 20mA(max).

Datasheet: https://www.czh-labs.com/tmp/madeimg/datasheet/d-1085.pdf
